UDO Audio DMNO Keyboard

DMNO is an 8-voice, 2-part multi-timbral powerhouse with a highly flexible and dynamic signal architecture. It features two fully independent 4-voice analog-hybrid synthesizers, each equipped with our new Dynamic Multi-Core Stereo VCF. With its eight creative Play Modes, DMNO unlocks dynamic interactions between the two timbres at the touch of a single control, while its flexible analog and digital audio connectivity makes it a truly expansive and immediate sound design sandbox.

At the core of DMNO is the Play Modes system. Instantly reconfigure the internal architecture at the touch of a single control with eight carefully curated modes that redefine how the two timbres interact — with traditional splits and layers sitting alongside novel, creative, and unexpected configurations. Complementing this versatility is a suite of flexible connectivity options, including an analog audio input with preamplifier, gate generator, and envelope follower, CV/Gate connections for the analog realm, and a 24-bit USB class-compliant digital audio interface.

Features:

• 8 voice polyphonic, with 4 ‘super’ voices when in Binaural mode. Binaural mode gives each channel (ear) a full synthesizer voice with independent detuning and modulation, creating an expansive, rich and texturally wide sound
• 2-Part Multitimbral, comprising 2 independent hybrid synthesizers, each with its own dedicated set of front-panel controls
• 8 selectable ‘Play Modes’ that immediately reconfigure DMNO’s signal flow, redefining how its two independent synth engines interact with one another
• Dynamic multicore stereo analog VCF with parallel, series and stereo connection modes — featuring multiple filter modes for each connection type
• Hybrid architecture: FPGA-based high-resolution digital oscillators paired with an analog signal path and a high-quality DSP eUects engine
• 44-key FATAR keybed with aftertouch
• 2-in 2-out 24-bit USB digital audio interface
• Stereo external audio input with a variable-gain preamplifier, gate level detector, and envelope-follower input to the modulation matrix
• Stereo auxiliary output that can be assigned to either DMNO 1/2, USB digital audio from the connected host, or the eUects send bus
• Two individual user-assignable CV & gate/clock outputs via 1/8”/3.5mm sockets
• High quality long-lasting electroluminescent glass vacuum fluorescent display (VFD) with dedicated rotary controls. Designed for immediacy with no deep menus and limited ‘hidden’ controls
• 32bit DSP digital eUects chain including delay, reverb, EQ, overdrive distortion and chorus
• Onboard 64-step sequencer with intuitive control via onboard display
